HIPOT TESTERS

A DIELECTRIC WITHSTAND TESTER (HIPOT TESTER) COMBINES A HIGH VOLTAGE GENERATOR (AC OR DC OR BOTH) AND A LEAKAGE CURRENT MEASURING DEVICE ASSOCIATED WITH A DISCHARGE SYSTEM.

This high voltage test (also called dielectric strength test, hipot test, hi-pot test, breakdown test or flash test) is made to stress the device under test with an AC or DC high voltage and check that there is no breakdown nor perforation happening. A hipot tester also checks that requested creepage and clearance distances are respected.

Most of the standards do not require voltages over 5kV. The hipot tests follow rules such as 2U + 1000V or 2U + 2000V, meaning 1480V or 2480V test voltage for 240Vac nominal functional voltage. These rules are given in international Low Voltage Directive (LVD) standards (IEC335, IEC 950, IEC601, IEC1010, IEC598, IEC990, IEC204 ).



HIPOT Testers Selection Guide

Product Description AC max test voltage DC max test voltage Current range Detection mode HMI Communication ports (fitted)
Hipot Testers SEFELEC 56-H
HIPOT Tester
5kVA AC - 6kV DC 50VA
Touchscreen display and control
IEC 61010-2-34 full compliant
5kV 6kV 0-10mA I max & Delta I TFT Touchscreen display Ethernet - USB - RS232 - PLC
Hipot Testers SEFELEC 506-H
HIPOT Tester
5kVA AC - 6kV DC 500VA
Touchscreen display and control
IEC 61010-2-34 full compliant
5kV 6kV 0-100mA I max & Delta I TFT Touchscreen display Ethernet - USB - RS232 - PLC
Hipot Testers PREMIER 2801
HIPOT Tester
5kVA AC 200VA
Matrix display and keys control
5kV 0-40mA I max & Delta I Matrix LCD display RS232 - API
Hipot Testers PREMIER 2802
HIPOT Tester
5kVA AC - 6kV DC 200VA
Matrix display and keys control
5kV 6kV 0-40mA I max & Delta I LCD Matriciel RS232 - API
Hipot Testers RMG12DC
Hipot tester
12KVDC
250VA
12kV 0-10mA I max & Delta I LCD Matriciel RS232
Hipot Testers RMG12AC/DC
Hipot tester
12 kV AC-DC

400 VA
12kV 12kV 0-50mA I max / Delta I LCD Matriciel RS232
Hipot Testers RMG15AC
Hipot tester
15 KVAC

500VA
15kV 0-30mA I max / Delta I Matrix LCD display RS232
Hipot testers DT Series
High voltage and high power hipot testers
from 3 kV à 400 kV
>15kV >12kV On demand I max & Burning PLC Ethernet - USB - RS232 - PLC- 0..10V
Hipot Testers EXS-3200
Switching module for up to 64 high voltage or high current channels. 5kV 6kV On demand / PLC RS232
CA003
Safety enclosure for 15KV HV tests - Large size.
Internal dimensions : Height: 373 mm x Width: 958 mm x Depth: 746 mm

in addition to SELELEC 5x, RMG and SYNOR, this enclosure is designed to perform HV tests safely.
CA001
Safety enclosure for 15KV HV tests - Small size.
Internal dimensions : Height: 212 mm x Width: 390 mm x Depth: 424 mm

in addition to SELELEC 5x, RMG and SYNOR, this enclosure is designed to perform HV tests safely.
Hipot Testers SEFELEC 56-H

0€

HIPOT Tester
5kVA AC - 6kV DC 50VA
Touchscreen display and control
IEC 61010-2-34 full compliant

5kV
6kV
0-10mA
I max & Delta I
TFT Touchscreen display
Ethernet - USB - RS232 - PLC
Hipot Testers SEFELEC 506-H

0€

HIPOT Tester
5kVA AC - 6kV DC 500VA
Touchscreen display and control
IEC 61010-2-34 full compliant

5kV
6kV
0-100mA
I max & Delta I
TFT Touchscreen display
Ethernet - USB - RS232 - PLC
Hipot Testers PREMIER 2801

0€

HIPOT Tester
5kVA AC 200VA
Matrix display and keys control

5kV
0-40mA
I max & Delta I
Matrix LCD display
RS232 - API
Hipot Testers PREMIER 2802

0€

HIPOT Tester
5kVA AC - 6kV DC 200VA
Matrix display and keys control

5kV
6kV
0-40mA
I max & Delta I
LCD Matriciel
RS232 - API
Hipot Testers RMG12DC

0€

Hipot tester
12KVDC
250VA

12kV
0-10mA
I max & Delta I
LCD Matriciel
RS232
Hipot Testers RMG12AC/DC

0€

Hipot tester
12 kV AC-DC

400 VA

12kV
12kV
0-50mA
I max / Delta I
LCD Matriciel
RS232
Hipot Testers RMG15AC

0€

Hipot tester
15 KVAC

500VA

15kV
0-30mA
I max / Delta I
Matrix LCD display
RS232
Hipot testers DT Series

0€

High voltage and high power hipot testers
from 3 kV à 400 kV

>15kV
>12kV
On demand
I max & Burning
PLC
Ethernet - USB - RS232 - PLC- 0..10V
Hipot Testers EXS-3200

0€

Switching module for up to 64 high voltage or high current channels.

5kV
6kV
On demand
/
PLC
RS232
CA003

0€

Safety enclosure for 15KV HV tests - Large size.
Internal dimensions : Height: 373 mm x Width: 958 mm x Depth: 746 mm

in addition to SELELEC 5x, RMG and SYNOR, this enclosure is designed to perform HV tests safely.

CA001

0€

Safety enclosure for 15KV HV tests - Small size.
Internal dimensions : Height: 212 mm x Width: 390 mm x Depth: 424 mm

in addition to SELELEC 5x, RMG and SYNOR, this enclosure is designed to perform HV tests safely.

* Please contact us for other currents

APPLICATION

MANUFACTURER, LABORATORIES, PRODUCTION LINES, MAINTENANCE IN ORDER TO COMPLY WITH LOW VOLTAGE DIRECTIVE
BANDEAUDIELSTRENGH

► Cables, breakers, batteries, communication devices manufacturers

► Electronic components manufacturers (capacitors, transistors, PCBs, IGBTs, relays …)

► Household appliances (Washing machines, cofee machines, Refrigerators, heaters, ovens...)

► Industrial equipment manufacturer (compressors, portable appliances & electric tools, transformers …)

► Lighting industry (lights, medical and professional…)

► Information Technology industry (servers, converters, terminals, printers, displays …)

► Competent Body laboratories (CE marking, specifications or compliance to standards certification…)

► Rail industry (Electric boards, harnesses, switches, catenaries, pantographs  …)

SEFELEC HIPOTS OVERALL SPECIFICATIONS

► Hipot test up to 400 kVAC & DC

► Wide range of accessories and safety enclosures

► Non-destructive dielectric withstand test with « ΔI » current detection method

► Burning test

► Native communication ports : RS232, PLC, Ethernet, USB. (IEEE-488.2 as an option)

► Winpass sofware suite for test control, supervision and personalized reports
