CABLE TESTERS - HIGH VOLTAGE WIRE HARNESS TEST SYSTEMS

SYNOR WIRE HARNESS TESTERS OFFERED BY EATON ARE AUTOMATIC TEST EQUIPMENT FOR WIRING HARNESSES, BACK BOARDS AND ALL COMPLEX ELECTRICAL EQUIPMENT.
Harness-web

These testers are the continuation of SEFELEC's know-how, since a cable harness tester carries out all the electrical measurements that we offer in stand-alone devices.





CABLE TESTERS Selection Guide

The SYNOR cable testers range is composed of switching boards all equipped with 2 relays per channel (possibility of grouped test). Each test point could therefore be individually brought to either the high or low voltage bus.

Product Description
Cable testers SYNOR5000-P
Compact high voltage cable tester
Cable testers SYNOR5000-H
High voltage cable tester in 7U high case
Cable testers SYNOR5000-R
6U rack high voltage cable tester to be integrated
Cable testers SYNOR5000-C
Full bench integrated high voltage tester
Cable testers SYNOR5000-P

0€

Compact high voltage cable tester

Cable testers SYNOR5000-H

0€

High voltage cable tester in 7U high case

Cable testers SYNOR5000-R

0€

6U rack high voltage cable tester to be integrated

Cable testers SYNOR5000-C

0€

Full bench integrated high voltage tester

APPLICATION

SEFELEC INVESTS A LOT IN R&D, BUT ALSO LISTENS TO HIS CUSTOMERS IN ORDER TO ALWAYS PROVIDE BETTER AND MORE ADAPTED SOLUTIONS FOR THE SYNOR CABLE TESTER USERS. SINCE MORE THAN 40 YEARS, OUR AUTOMATIC HIGH VOLTAGE CABLE TESTERS HAVE BEEN SOLD AROUND THE WORLD, IN MORE THAN 26 COUNTRIES, MOSTLY IN THE BELOW INDUSTRIES
EATON INVESTS A LOT IN R&D, BUT WE ALSO WORK WITH OUR CUSTOMERS IN ORDER TO ALWAYS PROVIDE BETTER AND MORE ADAPTED SOLUTIONS FOR THE SYNOR CABLE TESTER USERS. SINCE MORE THAN 40 YEARS, OUR AUTOMATIC HIGH VOLTAGE CABLE TESTERS HAVE BEEN SOLD AROUND THE WORLD, IN MORE THAN 26 COUNTRIES, MOSTLY IN THE INDUSTRIES LISTED BELOW :
BANDEAUCABLETESTER
  • Aerospace (satellites, launch vehicules, sub-assemblies…)
  • Aeronautic (planes, helicopters, optronics, unmanned air vehicles, sub-assemblies…)
  • Railways (trains, metro, tramways…)
  • Defense (radars, rockets, ucav, submarines, aircarfts…)
  • Connector manufacturers, telecommunication, electrical cabinets…

Our testers are installed both in production or in maintenance services.



TECHNICAL SPECIFICATION - HARDWARE

FROM 8 TEST POINTS TO 140 000 TEST POINTS, OUR CABLE TESTER RANGE INTEGRATES THE FOLLOWING FEATURES:

  • Continuity test in 2 and 4 wires mode up to 2 A
  • Insulation test up to 5000 VDC
  • Hipot test up to 5kV AC and 6kV DC
  • Component test (capacitor, resistance, diode, zener diode, inductance, GMOV, transorbs),shielding test, twisted pairs, coaxial cable measurement …
  • Stimuli and functional test for relay, light, speaker, engine activation, energisation …
  • Tester configuration : mobile, compact or distributed modules
  • Specific tests : optical fibers, reflectometry (distance to fault module, break point distance), 1553B bus, 3910 bus…
  • Integration of external devices (SEFELEC 5X, MGR10, ...) for higher specs availibility



TECHNICAL SPECIFICATION - SOFTWARE

WINPASS, OUR WINDOWS® BASED MULTI LANGUAGES SOFTWARE IS EASY TO LEARN, TO PROGRAM, TO USE, AND CAN ALSO BE CUSTOMIZED BY THE CUSTOMER FOR HIS OWN APPLICATION



  • automatic testing, connector library, equivalence tables, dialogues tables , self learning, self test, graphical results
  • production oriented - its fastness is an advantage, and data traceability (EXEL®, ACCESS®, WORD® reports) is today essential
  • high-technology oriented – some external SEFELEC equipment such as microhmmeter, teraohmmeter, hipot testers with very high specs can be easily controlled through the same ease and data traceability
  • our powerfull 3FC module lets you CONVERT one or hundreds of existing text files (from internal sources, other cable tester manufacturers, ...) or CAD files (ACCESS®, CATIA®, See One from XAO®, MENTOR®, ELSA®, ...) into Sefelec format files, with only 3 clicks
